GearUP 12V 100Ah LifePO4 Lithium Battery with Smart BMS + Bluetooth

The GearUP 12V 100Ah Lithium Iron Phosphate (LiFePO4) Battery is designed for high-performance energy storage, offering a robust solution for applications such as RVs, marine use, solar systems, and off-grid setups. With a built-in Battery Management System (BMS) and Bluetooth connectivity, this battery combines advanced technology with reliability and safety.

Key Features

1. High Cycle Life

• 6000+ Deep Cycles: The GearUP 12V 100Ah LiFePO4 battery is engineered to deliver over 6000 cycles at 80% Depth of Discharge (DOD), significantly outlasting traditional lead-acid batteries, which typically offer 200-500 cycles. This translates to a lifespan of up to 10 years or more, depending on usage.

2. Built-in 100A BMS

• Comprehensive Protection: The integrated 100A Battery Management System ensures safety and longevity by protecting against:

  • Overcharging

  • Over-discharging

  • Overcurrent

  • Short circuits

  • High and low-temperature conditions

• Low-Temperature Cut-Off: The BMS includes a low-temperature protection feature, halting charging below 0°C (32°F) to prevent cell damage, resuming when temperatures rise above 5°C (41°F). This makes it ideal for cold environments like winter RV camping or marine applications.

3. Bluetooth Connectivity

• Real-Time Monitoring: Bluetooth 5.0 enables users to monitor battery status via a dedicated smartphone app. Parameters such as voltage, charge/discharge current, state of charge (SOC), and protection status can be tracked in real-time, ensuring optimal performance and safety.

4. Lightweight and Compact

• Weight: Approximately 13.6 kg, roughly one-third the weight of equivalent lead-acid batteries, making it easier to handle and install.

5. High Energy Density

• Capacity: 100Ah at 12.8V, delivering 1280Wh of energy.

• Efficiency: Offers higher energy density and faster charging (up to 5 times faster than lead-acid batteries), reaching 80% charge in about one hour with a suitable charger.

6. Versatile Applications

• Suitable for:

  • RV camping

  • Marine and trolling motors

  • Solar energy storage

  • Off-grid systems

  • Home backup power

• Expandable: Supports up to 4 batteries in series (for 48V systems) and 15 in parallel (for increased capacity).

7. Safety and Certifications

• Grade A+ Cells: Utilizes A-grade LiFePO4 cells certified for safety (e.g., UL, CE, UN38.3).

• IP67 Waterproof: Both dust-tight and waterproof, capable of withstanding submersion in up to 1 meter of water for 30 minutes, making it suitable for harsh environments like marine or outdoor use.

• Non-Toxic: Free of heavy metals and rare earth elements, ensuring an environmentally friendly energy solution.

Performance Specifications

• Nominal Voltage: 12.8V

• Capacity: 100Ah (1280Wh)

• Max Continuous Charge Current: 100A

• Max Continuous Discharge Current: 100A

• Peak Discharge Current: 200A (3-5 seconds)

• Recommended Charging Voltage: 14.6V

• Recommended Charging Current: ≤50A

• Operating Temperature:

  • Discharge: -20°C to 60°C (-4°F to 140°F)

  • Charge: 0°C to 45°C (32°F to 113°F)

• Weight: ~13.6 KGs

• Dimensions: ~322*194*233mm

Advantages Over Lead-Acid Batteries

• Longevity: 10-15 times more cycles than lead-acid batteries.

• Weight: Approximately 1/3 the weight, reducing strain in mobile applications.

• Maintenance-Free: No watering or maintenance required, unlike lead-acid batteries.

• Faster Charging: Reaches full charge significantly quicker.

• Orientation Flexibility: Can be mounted in any direction without leakage risk.

Use Cases

• RV and Camping: Power appliances, lights, and electronics for extended trips.

• Marine: Ideal for trolling motors and fish finders, with robust BMS protection against water and salt spray.

• Solar Systems: Efficient energy storage for off-grid solar setups, compatible with MPPT controllers.

• Backup Power: Reliable for home or emergency power systems.

Charging Options

• LiFePO4 Charger: Recommended for optimal performance (e.g., 14.6V 20A charger for ~5-hour full charge).

• Solar Panels: Compatible with solar setups using MPPT controllers.

• Generator: Supports charging via a DC generator for off-grid scenarios.

Warranty and Support

• Warranty: 5-Years (2 Years Parts + Service and next 3 years only Service Warranty).

• Customer Support: GearUP provides support for troubleshooting and warranty claims, often including detailed manuals and responsive service.
